Product Name: 24 Slot Lead Frame Magazine for 72.85mm Wide Frames
Number: WBF47A01-000-R0
Size: 255(L)×79.2(W)×137.5(H)mm
Material: Aluminum alloy 6063(AL6063)
Number of slots: 24 slots
Slot Pitch: 5.08 mm
Initial slot position: 13.2 mm
Product Process: CNC precision machining
Surface treatment: Anodization
Structure Type:Integrated (One-Piece)
Product Name:10 Slot Lead Frame Magazine with 192mm Inner Width
Number:WBF44D10-000-R0
Size:336(L)X208(W)X184(H)mm
Material: Aluminum alloy 6061(AL6061)
Number of slots: 10 slots
Slot Pitch: 15 mm
Initial slot position: 24 mm
Product Process: CNC precision machining
Surface treatment:Anodization
Structure Type: Adjustable
Product Name:PEEK LEAD FRAME MAGAZINE 15 SLOTS
Number:WBF42C01-000-R0
Size:205(L)X98.9(W)X119 (H)mm
Material: Aluminum alloy 6061(AL6061)
Number of slots: 15 slots
Slot Pitch: 12.6mm
Initial slot position: 14.4mm
Product Process: CNC precision machining
Surface treatment: Hard Anodization
Structure Type: Assembly Magazine
Product Name: 20 Slot Lead Frame Magazine for 45.8 mm Wide Frames
Number: WBF40T24-000-R0
Size:249(L)X53.2(W)X138.2(H)mm
Material: Aluminum alloy 6061(AL6061)
Number of slots: 20 slots
Slot Pitch: 5.8mm
Initial slot position: 14.6mm
Product Process: CNC precision machining
Surface treatment: Anodization
Structure Type: Integrated (One-Piece)
Product Name: JY-20 Slot Lead Frame Magazine for 101 mm Wide Frames
Number: WBF40E53-000-R1
Size: 308(L)x107.6(W)x144.2(H)mm
Material: Aluminum alloy 6063（AL6063）
Number of slots: 20 slots
Slot Pitch: 6.35 mm
Initial slot position: 11.03mm
Product Process: CNC precision machining
Surface treatment: Anodization
Structure Type:Integrated(one-piece)Magazine
Product Name: 5 Slot Lead Frame Magazine for 128 mm Wide Frames
Number: WBF40TP2-000-R0
Size: 183(L)×101(W)×135(H)mm
Material: Aluminum alloy 6063(AL6063)
Number of slots: 5 slots
Slot Pitch: 15 mm
Initial slot position: 12.7 mm
Product Process: CNC precision machining
Surface treatment: Anodization
Structure Type: Integrated (One-Piece) Magazine
Product Name: 5 Slot Lead Frame Magazine for 217 mm Wide Frames
Number: WBF40C97-000-R2
Size: 323(L)×247(W)×160(H)mm
Material: Aluminum alloy 6061(AL6061)
Number of slots: 20 slots
Slot Pitch: 40 mm
Initial slot position: 32.5 mm
Product Process: CNC precision machining
Surface treatment: Anodization
Structure Type:Assembly Magazine
Product Name: 10 Slot Lead Frame Magazine for 60.5 mm Wide Frames
Number: WBF40A41-000-R0
Size: 128(L)×70.2(W)×127(H)mm
Material: Aluminum alloy 6061(AL6061)
Number of slots: 10 slots
Slot Pitch: 10.4 mm
Initial slot position: 12.6 mm
Product Process: CNC precision machining
Surface treatment: Anodization
Structure Type: Integrated (One-Piece) Magazine
Product Name: 10 Slot Lead Frame Magazine for76mm Wide Frames
Number: WBF40Z82-000-R4
Size: 210(L)×84(W)×139.8(H)mm
Material: Aluminum alloy 6063(AL6063)
Number of slots: 10 slots
Slot Pitch: 12 mm
Initial slot position: 14 mm
Product Process: CNC precision machining
Surface treatment: Anodization
Structure Type:Integrated (One-Piece)
