20 Slot Lead Frame Magazine for SOP 8 IC Package
Product Name: 20 Slot Lead Frame Magazine for SOP 8 IC Package
Number: WBF40S0P-00-R0
Size: 275(L)×90(W)×127.2(H)mm
Material: Aluminum alloy 6063(AL6063)
Number of slots: 20 slots
Slot Pitch: 5.2 mm
Initial slot position: 13.4 mm
Product Process: CNC precision machining
Surface treatment: Anodization
Structure Type: Integrated (One-Piece)
Product Description
Lead Frame Magazine
In the semiconductor manufacturing key step chip packaging and testing workshop, SOP8 chip packaging material magazine play an indispensable important role. Especially in the delicate wire bonding process, it becomes the core tool for storing and accessing lead frames.
The SOP8 chip packaging material magazine is specially designed for seamless integration with ASM wire bonding equipment. When the workshop initiates precision chip welding processes, it can seamlessly connect with ASM wire bonding equipment, accurately carrying and transporting lead frames to ensure each chip's precise positioning during welding. Its highly precise design enables smooth and stable transmission of lead frames to welding points even during high-speed, high-frequency bonding operations, building stable and accurate connection bridges between chips and external pins.
From technical specifications perspective, this material box strictly complies with ASM wire bonder's rigorous technical requirements. Whether in dimensional accuracy, maintaining tight tolerance ranges to match ASM equipment's precise mechanical structures; or in material selection, using lightweight, high-strength, wear-resistant premium aluminum profiles to prevent electrostatic damage or micro-debris contamination during chip processing, it comprehensively ensures chip packaging quality.
Q&A
Are you a factory or a trading company?
We are a factory.
How many staffs do you have in your factory?
Our company has nearly 70 staffs.
How many years have your company made this kind of equipment?
Our company has been serving the semiconductor industry for over 20 years, with extensive expertise in design and manufacturing.
What kinds of information do you need for a quote?
In order to quote for you earlier, please provide us with the following information together with your inquiry.
1.Product Model or Pictures
2.Material requirement(AL6063,AL6061,AL7075)
3.Surface treatment(Anodized，Hard Anodized，plating,sandblasting,brushing,etc)
4.Quantity(per order/per month/annual)
5. Any special demands or requirements, such as packing, delivery, labels, etc.
6.when do you expect to need the product?
What is your MOQ?
Standard products are available in stock with no minimum order quantity (MOQ) restrictions.
